High Efficiency Toothbrush Tufting Machine



High Efficiency Toothbrush Tufting Machine: The Perfect Combination of Speed, Precision, and Reliability

Our High Efficiency Toothbrush Tufting Machine is engineered to meet the demands of modern mass production. It perfectly integrates exceptional speed, ultimate precision, and unparalleled reliability, making it the ideal choice for boosting your production efficiency and cutting operational costs.



Core Advantages:



Extreme Speed: With an advanced servo control system and optimized mechanical structure, the machine operates at astonishing speeds, significantly shortening production cycles.



Ultimate Precision: High-precision CNC control ensures every bristle hole is perfectly positioned and every tuft is securely anchored, guaranteeing a high-quality final product.



Lasting Durability: Constructed with robust, industrial-grade materials and precision manufacturing, the machine delivers outstanding performance even under 24/7, high-intensity production environments, greatly reducing maintenance costs.

Whether you're producing standard toothbrushes or need to handle complex tufting patterns or special materials, our high-efficiency tufting machine can handle it with ease. Choosing our equipment is an investment in the future, making your production line smarter, more efficient, and more competitive.

ltem	Description	Unit	Parameter
1	Speed	Holes/Min	750-800
2	Hole Diameter	mm	1.2-3.8
3	Spindle quantity	Piece	6
4	Journey X axis	mm	50
	Journey Y axis	mm	25
1	Number of trim knife	set	2
2	Number of grinding head	Piece	8
3	Trimming and grinding speed	r/min	30-40
4	Vacuum efficiency	%	90
6	Air pressure	Mpa	0.6-0.8
7	Power voltage,frequence	V,HZ	380,50
	Machine Power	KW	2
8	Contour size(L*W*H)	mm	2000*1300*2000
9	Weight	KG	1500











Q: Is there a charge for training?

A: Basic training is free, additional in-depth training can be charged on demand.



Q: Does the export packaging of equipment meet international standards?

A: Yes, we use wooden crates for reinforcement, which meets the standard of sea transportation.



Q: Do you have a quality control team?

A: Yes, the quality control team is responsible for the whole process of quality supervision.



Q: Can hole patterns be programmed via CNC control? A: Yes, all hole patterns are precisely programmed using a CNC interface.



Q: How many spindles does the machine use? A: Most models use a single drilling spindle and a single tufting spindle.
