Full Automatic Toothbrush Finishing Machine
The Full Automatic Toothbrush Finishing Machine combines trimming, end-rounding, and polishing in one system, ensuring smooth, safe, and high-quality toothbrush heads. With advanced automation and CNC control, it reduces manual labor, improves production speed, and guarantees consistent results. Ideal for large-scale manufacturing, it helps toothbrush producers enhance efficiency, cut costs, and meet international quality standards.
|
Item |
Description |
Unit |
Parameter |
|
1 |
Max Speed |
Holes/min |
750 |
|
2 |
Maximum brush holes |
Holes/Piece |
≤100,000 |
|
3 |
Hole Diameter |
mm |
1.5-2.8 |
|
4 |
Spindle quantity |
Piece |
2+2 |
|
5 |
Journey X axis |
mm |
48 |
|
Jouney Y axis |
25 |
||
|
6 |
Maximum program quantity |
Piece |
2000 |
|
7 |
Air pressure |
Mpa |
0.6-0.8 |
|
8 |
Power voltage, frequence |
V,HZ |
220,50 |
|
Machine Power |
KW |
3 |
|
|
9 |
Contour size(LxWxH) |
mm |
1400x1250x1250 |
|
10 |
Weight |
KG |
1400 |
Machine Technical Parameter
|
Control System: |
PLC/Controller |
|
Disturbance Display: |
Chinese edition |
|
Safety Protection: |
Overload, Short circuit protection |
|
Lubrication: |
Auto Lubrication System |
|
Main Speed Control |
Frequence Lnventer |
|
Fiber Box |
Two Colours Box |
FAQ
| Q: Is it difficult to operate the equipment? |
| A: Equipped with Chinese/English touch interface, easy to operate. |
| Q: Is your equipment suitable for 24-hour operation? |
| A: Yes, the equipment is designed to support efficient operation around the clock. |
|
Q: Is preventive maintenance training provided? A: Yes, we provide comprehensive training as part of our installation service. |
|
Q: How often should cutting tools be replaced? A: Cutting tools should be replaced after 500,000 to 1 million cuts. |
|
Q: What materials are used for the frame? A: The frame is made from high-strength cast iron or welded steel plate. |
