CNC Broom Tufting Machine
The CNC Broom Tufting Machine is designed for high-efficiency and precise tufting of broom and brush products. It features a stable CNC control system, flexible programming for different hole patterns, and high-speed operation to meet mass production needs. With easy operation, low maintenance, and compatibility with various filament materials, it ensures consistent quality and productivity for industrial broom manufacturing.
|
Item |
Description |
Unit |
Parameter |
|
1 |
Max Speed |
Holes/min |
750 |
|
2 |
Maximum brush holes |
Holes/Piece |
≤100,000 |
|
3 |
Hole Diameter |
mm |
1.5-2.8 |
|
4 |
Spindle quantity |
Piece |
2+2 |
|
5 |
Journey X axis |
mm |
48 |
|
Jouney Y axis |
25 |
||
|
6 |
Maximum program quantity |
Piece |
2000 |
|
7 |
Air pressure |
Mpa |
0.6-0.8 |
|
8 |
Power voltage, frequence |
V,HZ |
220,50 |
|
Machine Power |
KW |
3 |
|
|
9 |
Contour size(LxWxH) |
mm |
1400x1250x1250 |
|
10 |
Weight |
KG |
490 |
Machine Technical Parameter
|
Control System: |
PLC/Controller |
|
Disturbance Display: |
Chinese edition |
|
Safety Protection: |
Overload, Short circuit protection |
|
Lubrication: |
Auto Lubrication System |
|
Main Speed Control |
Frequence Lnventer |
|
Fiber Box |
Two Colours Box |
FAQ
| Q: How to ensure after-sales satisfaction? |
| A: We make regular return visits and our customer satisfaction rate is over 99%. |
| Q: Does Kai Yue have international certification? |
| A: Yes, the company has passed ISO9001 international quality management system certification. |
| Q: Is the factory green? |
| A: Yes, we actively use environmentally friendly processes to reduce emissions. |
|
Q: Is there a system to detect missing bristles? A: Some high-end models offer an optional vision inspection system for this purpose. |
|
Q: How does the machine ensure consistent bristle anchoring? A: It uses a high-precision tufting head and a servo-driven mechanism for uniform force. |
